In this paper, the rapid drawdown scenario is analyzed by means of numerical examples as well as modeling of real cases with in situ measurements. The aim of the study is to evaluate different approaches available for calculating pore water pressure distributions during and after a drawdown. To do that, a single slope subjected to a drawdown is first analyzed under different calculation alternatives, and numerical results are discussed. Simple methods, such as the undrained analysis and pure flow analysis, implicitly assuming a rigid soil skeleton, lead to significant errors in pore water pressure distributions when compared with the coupled flow-deformation analysis. In the second case study, a similar analysis is performed for the upstream slope of the Glen Shira Dam, Scotland, and numerical results are compared with field measurements during a controlled drawdown. Field records indicate that classical undrained calculations are conservative but unrealistic. Then, a recent case of a major landslide triggered by a rapid drawdown in a reservoir is interpreted. A key aspect of the case is the correct characterization of permeability of a representative soil profile. This is achieved by combining laboratory test results and a back analysis of pore water pressure time records during a period of reservoir water level fluctuations. The results highlight the difficulty of predicting whether the pore water pressure is overestimated or underestimated when using simplified approaches, and it is concluded that predicting the pore water pressure distribution in a slope after rapid drawdown requires a coupled flow-deformation analysis in saturated and unsaturated porous media.
Abstract:
Generally, most soil slope failures are induced by rainfall infiltration, a process that involves interactions between the liquid phase, gas phase, and solid skeleton in an unsaturated soil slope. In this study, a loosely coupled liquid-gas-solid three-phase model, linking two numerical codes, TOUGH2/EOS3, which is used for water-air two-phase flow analysis, and FLAC3D, which is used for mechanical analysis, was established. The model was validated through a documented water drainage experiment over a sandy column and a comparison of the results with measured data and simulated results from other researchers. The proposed model was used to investigate the features of water-air two-phase flow and stress fields in an unsaturated soil slope during rainfall infiltration. The slope stability analysis was then performed based on the simulated water-air two-phase seepage and stress fields on a given slip surface. The results show that the safety factor for the given slip surface decreases first, then increases, and later decreases until the rainfall stops. Subsequently, a sudden rise occurs. After that, the safety factor decreases continually and reaches its lowest value, and then increases slowly to a steady value. The lowest value does not occur when the rainfall stops, indicating a delayed effect of the safety factor. The variations of the safety factor for the given slip surface are therefore caused by a combination of pore-air pressure, matric suction, normal stress, and net normal stress.
Abstract:
Seismic responses of the Zipingpu concrete face rockfill dam were analyzed using the finite element method. The dynamic behavior of rockfill materials was modeled with a viscoelastic model and an empirical permanent strain model. The relevant parameters were obtained either by back analysis using the field observations or by reference to parameters of similar rockfill materials. The acceleration responses of the dam, the distribution of earthquake-induced settlement, and the gap propagation under the concrete slabs caused by the settlement of the dam were analyzed and compared with site investigations or relevant studies. The mechanism of failure of horizontal construction joints was also analyzed based on numerical results and site observations. Numerical results show that the input accelerations were considerably amplified near the top of the dam, and the strong shaking resulted in considerable settlement of the rockfill materials, with a maximum value exceeding 90 cm at the crest. As a result of the settlement of rockfill materials, the third-stage concrete slabs were separated from the cushion layer. The rotation of the cantilever slabs about the contacting regions, under the combined action of gravity and seismic inertial forces, led to the failure of the construction joints and tensile cracks appeared above the construction joints. The effectiveness and limitations of the so-called equivalent linear method are also discussed.
Abstract:
Based on the concrete damage constitutive model, the Weibull distribution function was used to characterize the random distribution of the mechanical properties of materials by finely subdividing concrete slab elements, and a concrete random mesoscopic damage model was established. The seismic response of a 100-m high concrete face rockfill dam (CFRD), subjected to ground motion with different intensities, was simulated with the three-dimensional finite element method (FEM), with emphasis on exploration of damage and the cracking process of concrete slabs during earthquakes as well as analysis of dynamic damage and cracking characteristics during strong earthquakes. The calculated results show that the number of damaged and cracked elements on concrete slabs grows with the duration of earthquakes. With increasing earthquake intensity, the damaged zone and cracked zone on concrete slabs grow wider. During a 7.0-magnitude earthquake, the stress level of concrete slabs is low for the CFRD, and there is almost no damage or slight damage to the slabs. While during a 9.0-magnitude strong earthquake, the percentages of damaged elements and macrocracked elements continuously ascend with the duration of the earthquake, peaking at approximately 26% and 5% at the end of the earthquake, respectively. The concrete random mesoscopic damage model can depict the entire process of sprouting, growing, connecting, and expanding of cracks on a concrete slab during earthquakes.
Abstract:
Reinforced concrete core dams can be an alternative solution to conventional dam designs either for permanent impounded reservoirs or flood protection and flood-retaining dams. The dams of this type were constructed in Austria for various reasons and showed good behavior during operation. For a better understanding of the load-deformation behavior of such type of dams during construction and impounding, numerical simulations have been carried out. The interaction between the thin reinforced concrete core and the dam fill material as well as the influence of fill material properties and other main parameters, such as the roughness of the concrete surface and bedding conditions of the concrete core, on the deformation behavior of dams are studied. The results show that high compressive stress is mainly induced by arching effects in the dam body during construction. During the reservoir impounding, the compressive stresses in the core are reduced significantly while the bending moment in the core footing increases. The results also show that the maximum bending moments occur at the core footing and can be significantly reduced by design improvements. The findings in this study can provide general design recommendations for small dams with a central concrete core as a sealing blanket.
Abstract:
The cut-off wall in a clay-core rockfill dam built on a thick overburden layer is easily subjected to a great compressive pressure under the action of the loads such as the dead weight of both the dam and the overburden layer, the frictional force induced by the differential settlement between the cut-off wall and its surrounding soils as well as the water pressure. Thus, how to reduce the stress of the cut-off wall has become one of the main problems that need to be considered in the engineering design. In this paper, numerical analysis of a core rock-fill dam built on a thick overburden layer was conducted and some factors influencing the stress-strain behaviors of the cut-off wall were investigated. The factors include the improvement of the overburden layer, the modeling approach for interfacial contact between the cut-off wall and its surrounding soils, the modulus of the cut-off wall concrete, and the connected pattern between the cut-off wall and the clay core. The result shows that improving the overburden layer, selecting plastic concrete with a low modulus and a high strength, and optimizing the connection between the cut-off wall and the clay core of the dam are effective measures to reduce the deformations and compressive stresses of the cut-off wall. Besides, both the Goodman element and mud-layer element are suitable for simulating the interfacial contact between the cut-off wall and its surrounding soils.
Abstract:
In this paper, two different concepts for the constitutive modeling of the mechanical behavior of creep-sensitive rockfill materials are presented. Specifically, the performance of an extended generalized plasticity model proposed by Wang is compared with a simplified version of the hypoplastic constitutive model for weathered rockfill materials proposed by Bauer. Both models can reflect the influence of the mean stress on the incremental stiffness, the peak friction angle, and the dilatancy angle. The so-called solid hardness defined for a continuum description and originally introduced by Bauer is embedded in both models. Hydrochemical, thermal, and mechanical weathering are usually caused by environmental changes and are taken into account in a phenomenological description with an irreversible and time-dependent degradation of the solid hardness. A degradation of the solid hardness is usually accompanied by creep deformation of the stressed rockfill material. It is shown that appropriate modeling of creep deformation requires at least a unified description of the interaction between the time-dependent process of degradation of the solid hardness and the stress state. In this context, the solid hardness can be understood as a key parameter for describing the evolution of the state of weathering of the rockfill material. Particular attention is also paid to the necessary procedure for determining the constitutive constants of the two different constitutive models. Finally, the performance of the two different constitutive models is demonstrated by comparing the results obtained from numerical simulations with experimental data from the creep-sensitive rockfill material.
Abstract:
To study the stress, deformation, and seepage pressure during the initial impoundment of the Jinping-I Arch Dam, monitoring analysis and numerical calculation were comprehensively used in the dam behavior analysis, focusing on the working behavior of the dam during the late period of the initial impoundment by the end of November 2014. The numerical calculation was performed based on feedback analysis of the deformation and stress of the arch dam by inversion of the elastic moduli (E) of the dam body and foundation, in which a three-dimensional finite element model for linear elastic material of the arch dam was developed. Results show that, the main monitoring indices presented insignificant changes in the late period of the initial impoundment, and the results of feedback analysis were consistent with monitoring results. Analysis results also show that the deformations of the dam body and dam foundation were within the design range, the dam stress distributions were normal with the values lower than the design control criteria, and the seepage flows through the dam body and dam foundation were lower than the design drainage capacity of the deep-well pump house, demonstrating that the working behavior of the Jinping-I Arch Dam was in a good condition, and the initial impoundment was successfully completed. The results about the working behavior analysis of the Jinping-I hydropower project during the initial impoundment can provide references for safe operation of similar projects.
Abstract:
In this study, we investigated the origin of the overland flow roughness problem and divided the current overland flow roughness research into three types, as follows: the first type of research takes into account the effects of roughness on the volume and velocity of surface runoff, flood peaks, and the scouring capability of flows, but has not addressed the spatial variability of roughness in detail; the second type of research considers that surface roughness varies spatially with different land usage types, land-cover conditions, and different tillage forms, but lacks a quantitative study of the spatial variability; and the third type of research simply deals with the spatial variability of roughness in each grid cell or land type. We present three shortcomings of the current overland flow roughness research, including (1) the neglect of roughness in distributed hydrological models when simulating the overland flow direction and distribution, (2) the lack of consideration of spatial variability of roughness in hydrological models, and (3) the failure to distinguish the roughness formulas in different overland flow regimes. To solve these problems, distributed hydrological model research should focus on four aspects in regard to overland flow: velocity field observations, flow regime mechanisms, a basic roughness theory, and scale problems.
Abstract:
The Green-Ampt (G-A) infiltration model (i.e., the G-A model) is often used to characterize the infiltration process in hydrology. The parameters of the G-A model are critical in applications for the prediction of infiltration and associated rainfall-runoff processes. Previous approaches to determining the G-A parameters have depended on pedotransfer functions (PTFs) or estimates from experimental results, usually without providing optimum values. In this study, rainfall simulators with soil moisture measurements were used to generate rainfall in various experimental plots. Observed runoff data and soil moisture dynamic data were jointly used to yield the infiltration processes, and an improved self-adaptive method was used to optimize the G-A parameters for various types of soil under different rainfall conditions. The two G-A parameters, i.e., the effective hydraulic conductivity and the effective capillary drive at the wetting front, were determined simultaneously to describe the relationships between rainfall, runoff, and infiltration processes. Through a designed experiment, the method for determining the G-A parameters was proved to be reliable in reflecting the effects of pedologic background in G-A type infiltration cases and deriving the optimum G-A parameters. Unlike PTF methods, this approach estimates the G-A parameters directly from infiltration curves obtained from rainfall simulation experiments so that it can be used to determine site-specific parameters. This study provides a self-adaptive method of optimizing the G-A parameters through designed field experiments. The parameters derived from field-measured rainfall-infiltration processes are more reliable and applicable to hydrological models.
